18: QoS: VLAN 802.1Q PCP tagging

_______________________________________________________________________________________________________

_____________________________________________________________________________________________________

GW1000 Series User Manual

Issue: 1.9 Page 137 of 350

option vlan_qos_map_ingress '3:3'

option vlan_qos_map_egress '0:3'

config interface 'VLAN_4'

option ifname 'eth3 eth4.4'

option type 'bridge'

option proto 'static'

option ipaddr '192.168.3.1'

option netmask '255.255.255.0'

option vlan_qos_map_ingress '5:5'

option vlan_qos_map_egress '0:5'

UCI/Package Option

Description

UCI: network.<if

name>.vlan_qos_map_ingress

Opt: list vlan_qos_map_ingress

VLAN priority code point to socket buffer mapping.

Example: network.<if name>. vlan_qos_map_ingress =1:1

UCI: network.<if

name>.vlan_qos_map_egress

Opt: list vlan_qos_map_egress

Socket buffer to VLAN priority code point mapping.

Example: network.<if name>. vlan_qos_map_egress =0:1

The above sample configuration specifies that any frames on VLAN2, VLAN3 and VLAN4

will be processed or have their PCP value adjusted according to QoS values set.

VLAN1

 VLAN1 is an untagged VLAN so there are no 802.1Q tags on the frames.

VLAN2

 Any frames received on VLAN2 destined to VLAN2 with PCP priority of 1 will be

forwarded without altering the priority; it will be still set to 1.

 Any frames received on VLAN2 destined to VLAN2 with a PCP priority set to 0 will

have a priority of 1 set as they leave the router on VLAN2.

VLAN3

 Any frames received on VLAN3 destined to VLAN3 with a PCP priority of 3 will be

forwarded without altering the priority; it will be still set to 3.

 Any frames received on VLAN3 destined to VLAN2 with PCP priority set to 0 will

have a priority of 3 set as they leave the router on VLAN3.

VLAN4

 Any frames received on VLAN4 destined to VLAN2 with PCP priority of 5 will be

forwarded without altering the priority; it will be still set to 5.

 Any frames received on VLAN4 destined to VLAN2 with PCP priority set to 0 will

have a priority of 5 set as they leave the router on VLAN4.
