Visionix EyeRefract User Guide
43
Overview of the Software
7
WF Ref data-set
Initially displays the results of the wavefront analysis. As the subjective refraction
progresses, the values are modified based on the patient's responses.
During the subjective refraction, when this eye is being tested, the data set in this
column is called #2, as it is for the right eye in the illustration above.
Note: The actual results of the wavefront analysis are not modified during the
subjective refraction. They can be seen in the Exam File screen.
8
LM data-set
If lens meter data was entered before measurement then the data will be displayed
on this column . As the subjective refraction will be done around the lm and WF, if
there is no LM data then wf data will be also shown on this column ,the settings are
modified based on the patient's responses.
During the subjective refraction, when this eye is being tested, the data set in this
column is called #1, as it is for the right eye in the illustration above.
Note: The LM data-set settings are not modified during the subjective refraction.
They can be seen in the Exam File screen.
9
End Exam button
When the refraction is complete, tap to open the Exam File screen, in which you
can print or export the final results of the refraction.
10
Decrease Value button
Tap to reduce the value that is currently selected by the increment indicated in the
Step field (#11).
11
Step
The increment by which the currently selected value is raised or lowered each time
the Increase Value (#10) or Decrease Value (#13) buttons are tapped, or when
the Adjust Value dial (#12) is moved to the right or left one notch
Tap to open a dialog box in which you can choose a different step (or select a fixed
value for the axis).
12
Adjust Value dial
Drag to the right or left to raise or lower the currently selected value.
13
Increase Value button
Tap to raise the value that is currently selected by the increment indicated in the
Step field (#11).
14
Equivalency button
Tap if the patient says the prescriptions in columns #1 and #2 are equally good.
15
#2 Preferred button
Tap if the patient says the prescription in column #2 is better than the one in
column #1.
16
#1 Preferred button
Tap if the patient says the prescription in column #1 is better than the one in
column #2.
Manual Refraction
Manual Refraction is available just from Quick Pro Mode, you have direct control over all of the
system's features by clicking on the refraction tabs. The right side of the Refraction screen
contains a chart display and chart controls, and the left side of the screen displays the
refraction values, which you can modify as required. As you proceed, the phoropter
automatically resets the lenses to match the refraction values you enter.
