300004969171/B Page 133 of 148
Guidance and manufacturer’s declaration – electromagnetic immunity
The Volcano System Family Image Intensifier is intended for use in the electromagnetic
environment specified below. The customer or the user of the Volcano System Family should
assure that it is used in such an environment.
Immunity Test IEC Test Level Compliance
Level
Electromagnetic
environment-guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for
input/output
lines
±2 kV for power
supply lines
±1 kV for
input/output
lines
Mains power quality should
be that of a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
±0.5, ±1 kV
line(s) to line(s)
±0.5, ±1, ±2 kV
line(s) to earth
±0.5, ±1 kV
differential mode
±0.5, ±1, ±2 kV
common mode
Mains power quality should
be that of a typical
commercial or hospital
environment.
Conducted Disturbances
EN 61000-4-6
Amplitude 3 Vrms
6 Vrms in
ISM/Amateur
bands
Modulation 80%,
1kHz sine wave
Amplitude 3 Vrms
6 Vrms in
ISM/Amateur
bands
Modulation 80%,
1kHz sine wave
Mains power quality should
be that of a typical hospital
environment.
The Range of 5MHz to
50MHz may demand
further separation of
distance from intentional
radiators. The imaging
catheters operate in this
frequency band, and will
be very sensitive to
transmissions from
intentional, incidental, or
accidental radiators.
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
0% U
T
; 0.5
Cycle
At 0
o
, 45
o
, 90
o
,
135
o
, 180
o
, 225
o
,
270
o
, and 315
o
0% U
T
; 0.5
Cycle
At 0
o
, 45
o
, 90
o
,
135
o
, 180
o
, 225
o
,
270
o
, and 315
o
Mains power quality should
be that of a typical
commercial or hospital
environment. If the user of
the Volcano System Family
