NOTE 2: Edits made in the tomographic view are represented in the ILD view, and vice-
versa.
NC/DC Only Mode
NC/DC only mode is an alternative display of the VH data that only displays NC and DC
colors. FF and FI are not displayed in this mode. Please note that in this mode, the
autoborders will be adjusted so that the inner border is fixed right around the transducer
perimeter.
NOTE: It is recommended to consult with your local Volcano representative prior to
using this feature.
This mode can be activated in Settings under the VH-IVUS tab. Please note that this mode
must be selected prior to acquisition. If an image (saved frame or video loop) is collected in
NC/DC mode, it cannot be displayed in full VH mode.
Figure 45: NC/DC Only Mode
