VOLKTEK NSH-5509 User Manual

VOLKTEK NSH-5509 MANAGED 8-PORT 10/100 + 1-PORT 100-FX SWITCH
8.11.3 IP ToS Priority
The IP ToS (Type of Service) Priority menu provides different priorities. The user can
select the most suitable combination.
8.12 Management Configuration
8.12.1 Serial Port Configuration
Here the user can see the serial port configuration that can be utilized while accessing
the switch via Console port.
Click on each parameter field to modify the desired setting, then click “Apply” to
implement newly entered information or click “Undo” to restore previously saved
configurations.
Parameter Description
Management Mode,
Baud Rate, Data Bits,
Stop bits, Parity
Time Out
Default COM port properties
Set the time (seconds) for auto-logout in case there is no activity for
that time period
41
