VOLKTEK NSH-5509 MANAGED 8-PORT 10/100 + 1-PORT 100-FX SWITCH
Then, you can type in “?” or “help” followed by “Enter” key to display a full list of help
commands with explanations of their functions.
9.3.2 Spanning Tree Protocol (STP) configurations
STP allows the Switch to assign a priority status on the Switch with respect to other
networking nodes in the network. Ensure that this function is activated when setting up
backup links and to avoid loop.
Type a question mark “?” after spanning-tree command to display a full list of help
commands with explanations.
NSH-5009(config)# spanning-tree
enable Enable RSTP on the switch
force-version Set RSTP force version
forward-delay Set RSTP forward delay
hello-time Set RSTP hello time
max-age Set RSTP max age
priority Set RSTP switch priority
9.3.3 Virtual LAN configurations
Before you configure VLAN parameters, you should setup the VLAN type to “Tag-Based”.
For example, use the following commands to setup tag-based VLANs:
NSH-5009(config)# vlan-type 802.1q
NSH-5009(config)# vlan 1
NSH-5009(config-vlan)#
Type a question mark “?” or “help” followed by Enter to display a full list of help
commands with explanations.
NSH-5009(config-vlan)# help
Commands available:
exit Exit from current mode
help Show available commands
history Show a list of previously run commands
logout Disconnect
ping Ping a specified host with IP address
manage This VLAN Group ID is a management VLAN
member Specify the port(s) you don't want to
modify all outgoing frames transmitted
with this VLAN Group ID
non-member Specify the port(s) don't a member for
this VLAN Group ID
tagging Specify the port(s) you want to tag all
outgoing frames transmitted with this VLAN
Group ID
untagging Specify the port(s) you don't want to tag
51
