18
FIG. 3
FITTING THE MECHANICAL CABLES
FASTENING THE FRONT PLATE
SECURES THE CABLES IN
PLACE.
SCREW THE HOLDER 7-10 MM
ONTO THE CABLE THREAD.
MAKE SURE TO TIGHTEN THE
LOCKING NUT PROPERLY.
SECURE THE THROTTLE CABLE
WITH LOCKING NUTS ON BOTH
SIDES.
Installation Instructions
