4-42 BA 357-00 * 3.0 * 35700_04_Inbetriebnahme_03.fm
4 Putting into operation
Indication Meaning
G
Indicator display – holding function
(active standstill control)
Illuminates when the holding function is enabled
– see chapter 5 “Parking brake” on page 5-6.
Warning indicator – hydraulic oil filter
contamination
Illuminates if the resistance of the oil flow
in the return filter is too high
– see chapter 7 “Monitoring the hydraulic oil filter” on
page 7-54.
Warning indicator – hydraulic motor temperature
Illuminates if the temperature
in the hydraulic motor is too high
– see "Warning light (red) – temperature" on
page 4-35.
Warning indicator – operating motor temperature
Illuminates if the temperature in the operating motor
is too high
– see "Warning light (red) – temperature" on
page 4-35.
Warning indicator – hydraulic oil temperature
Illuminates if the temperature of the hydraulic oil in
the return filter is too high
– see chapter 7 “Monitoring the hydraulic oil filter” on
page 7-54.
