5-36 BA 357-00 * 3.0 * 35700_05_Bedienung.fm
5 Operation
Oil volume setting
Using the oil volume setting during continuous operation of the 3rd control
circuit (– see "Continuous operation of 3rd control circuit" on page 5-44) to
set the rpm of the operating motor and thus indirectly the flow rate of the
hydraulic pump. The flow rate, in turn, has an impact on the hydraulic
function of the attachments.
If an additional speed is required because other hydraulic functions are
being used at the same time (e.g. raising/lowering the loader unit) that is
above the speed set with the oil volume setting, the speed will be raised to
the needed value for as long as the requirement persists.
The oil volume setting requires the following conditions to be fulfilled:
• Machine is turned on and ready to operate
– see chapter 4 “Turn on the machine” on page 4-54.
• Operator is sitting in position.
• Joystick lock for road travel is unlocked
– see chapter 4 “Locking/unlocking the control lever (joystick)” on
page 4-51.
The rotary switch for the oil volume adjustment 75 is located on the rear
switch panel to the right of the operator seat.
The oil volume can be set variably between 0 % (700 min
-1
)
and 100 % (3000 min
-1
). Ex works, the oil volume is set to 100%.
The selected oil volume is set permanently until it is changed manually.
The oil volume settings can only be increased / reduced during machine
operation, e.g. the number of revolutions a rotary broom makes.
