WAGNER PROTEC 95-150 - Page 66

66
VERSION 01/2020
ORDER NUMBER DOC2340282
IceBreaker 150-300 cm
3
Tiger 12
DesignationOrder no.
1 1 2329627 Air motor, complete
2 1 369324 Shoulder ring
3 1 369325 Lifting eye nut
4 1 2328610 Pressure regulator unit 12 (incl. Pos. 40)
5 2 367405 Control air pipe 150
6 1 370303 Piston disk 12
7 2 370304 Damping disk 12
8 1 370385 Piston 12
9 1 370402 Piston rod 12/150
10
1 2386162 Self-locking hexagon nut (new)
1 9913051 Hexagon nut, secured with Loctite® 243 (old version!)
11 1 9974261 O-ring
13 1 9952668 Base
14 1 9952667 Clamping bracket
15 1 9921505 Spring washer
16 1 9900701 Socket cap screw with slit
17 1 370307 Gauging pin
18 2 370309 Valve cover
19 2 370310 Spiral spring
20 2 370311 Screw plug
21 2 370312 Valve body
22 2 9922724 Lock washer
23 2 9974102 O-ring
24 1 370316 Flange 12
25 1 9962026 Permaglide bushing
26 1 9971446 O-ring
27 1 9974158 Scraper ring D35
28 1 9974159 Rod seal D35
29 1 9998675 Threaded plug
30 2 9998274 Threaded plug
31 1 370306 Air tube 12
32 1 370403 Cylinder tube 12/150
33 1 9971129 O-ring
35 4 9974089 O-ring
36 1 369311 Hood 9
37 1 369319 Sound absorbing mat 9
38 1 2330374 Wagner 12 Tiger label
39 1 9900150 Hexagon screw
41 8 9907208 Hexagon screw
42 5 9907125 Screw
43 8 9920107 Washer
44 1 9925034 Washer
45 1 369310 Silencer 9
46 1 369318 Shoulder screw 9
47 1 367314 Control air lter
48 1 367324 Filter holder
49 1 367325 Throttle
= wearing parts
= Included in service set
