IceBreaker 150-300 cm
3
Tiger 12
DesignationOrder no.
50 1 369309 Connecting part 9
51 1 369313 Compressed air lter 9
52 2 369312 Outlet seal DE 50
53 1 370313 Stop plate 12
54 1 370314 Sealing plug 12
55 1 370315 Control housing 12
56 2 370330 Securing ring
57 1 9943121 Spool and sleeve assembly
58 6 9974160 O-ring
59 1 2302480 Safety valve, 7.8 bar
60 1 9970149 Sealing ring
61 2 9974092 O-ring
62 2 9998253 Threaded elbow tting, 8-1/4"
63 2 9992757 Threaded elbow tting, 8-1/8"
64 1 370233 Air hose, front
65 1 370234 Air hose, rear
66 2 370235 Air hose, below
67 1 370308 Gauging pin
68 1 370317 Control-ange 12
69 1 370404 Compressed air tube 12
70 4 9900313 Socket cap screw
71 3 9900314 Socket cap screw
72 4 9920102 Washer
73 3 9925029 Washer
74 5 9971004 O-ring
75 1 9971129 O-ring
76 1 9971372 O-ring
77 2 9974132 O-ring
78 1 9992757 Threaded elbow tting, 8-1/8"
79 1 9998613 Fitting L
80 1 2330382 IceBreaker label
81 2 370318 Pin for control ange
82 1 9992744 Straight threaded tting
83 1 9992743 Straight threaded tting
84 2 9907125 Screw SFS Plastite 45
85 2 9925031 Washer
86 1 9974165 O-ring
90 1 370323 Elbow ball valve housing 12
107 1 2332077 Warning label
108 1 9999151 Velcro fastener adhesive part
109 1 9999152 Velcro fastener coating part
111 1 9992816 Miranit contact adhesive
112 1 9992590 Loctite 222 50 ml; 50 cc
114 1 9992831 Loctite 542 50 ml; 50 cc
115 1 9992616 Molykote DX grease
116 1 9998808 Mobilux EP 2 grease
118 1 2332082 Fluid warning label
1 370987 12" air motor service set
1 9992511 Loctite 243 50 ml; 50 cc
= wearing parts
= Included in service set
