Waldorf microQ Keyboard User Manual

Appendix – Controller Numbers
Waldorf microQ User´s Manual 152
Controller Numbers
Controllers marked with * don’t change the Sound program but can perform temporary modulations
or other tasks.
Ctrl # Controller Range Controller Name or
Sound Parameter
Value Range
0 - not used - Bank Select MSB - not used -
1 0…127 Modulation Wheel* 0…127
2 0…127 Breath Control* 0…127
3 - not used - undefined - not used -
4 0…127 Foot Control* 0…127
5 0…127 Glide Rate 0…127
6 - not used - Data Entry - not used -
7 0…127 Channel Volume* 0…127
8 - not used - Balance - not used -
9 - not used - undefined - not used -
10 0…127 Pan* L64…R63
11 - not used - Expression - not used -
12 0…9 Arp Range 1…10 octaves
13 0…15 Arp Length 1…16 steps
14 0…3 Arp Active off, on, one shot, hold
15 0…5 LFO 1 Shape sine, triangle, square, sawtooth, random, S&H
16 0…127 LFO 1 Speed 0…127 or 256 bars…1/96
17 0…1 LFO 1 Sync off, on
18 0…127 LFO 1 Delay 0…127
19 0…5 LFO 2 Shape sine, triangle, square, sawtooth, random, S&H
20 0…127 LFO 2 Speed 0…127 or 256 bars…1/96
21 0…1 LFO 2 Sync off, on
22 0…127 LFO 2 Delay 0…127
23 0…5 LFO 3 Shape sine, triangle, square, sawtooth, random, S&H
24 0…127 LFO 3 Speed 0…127 or 256 bars…1/96
25 0…1 LFO 3 Sync off, on
26 0…127 LFO 3 Delay 0…127
27 16, 28, 40…112 Osc 1 Octave 128’…1/2’
28 52…76 Osc 1 Semitone -12…+12
29 0…127 Osc 1 Detune -64…+63
30 0…127 Osc 1 FM 0…127
31 0…5 Osc 1 Shape pulse, saw, triangle, sine, alt 1, alt 2
