Waldorf microQ Keyboard User Manual

Multi Mode – Instrument settings
Waldorf microQ User´s Manual 44
Multi Mixer (not available for the microQ lite)
VOL
ˇ_____ˇ____ˇ____ 127
The Multi Mixer offers fast graphical editing of Volume, Panning and Effect Send for all 16
instruments. The 16 horizontal segments represent the 16 available instruments. A small cursor below
the corresponding segment indicates the chosen instrument. With the red dial you can switch
between Level Mode and VU Mode.
Level Mode
In Level Mode the settings for all 16 instruments can be quickly edited. The left display knob selects
the desired parameter. The right display knob changes the value. You can easily compare values for
all 16 instruments at the same time. The following parameters are available:
• Vol shows the actual volume of the instruments in Multimode. Here the volume can be
changed infinitely variable from 0 to 127
• FX1 shows the FX1 Mix Level of the Multi Instruments. It can be changed infinitely variable
from 0 to 127.
• FX2 shows the FX2 Mix Level of the Multi Instruments. It can be changed infinitely variable
from 0 to 127.
VU Mode
The VU Mode graphically shows all incoming Midi signals and current signal volume as a bargraph
(like on a signal analyzer.) This allows you to check which instruments are receiving Midi messages.
All of the Multimode parameters can be changed while in VU Mode. In addition to the Level Mode
parameters, the following parameter is also available:
• PAN sets the panorama position infinitely variable from 0 to 127
 The Multi Mixer offers the possibility to mute or unmute instruments during a live performance.
