Hardware
Slowly thread the control cabinet into the
locating pins, slowly lower it and gently
tighten the two screws.
Hold the slide - as shown in the figure -
approx. 3 cm above the platform against
the control cabinet profile. Here, the slide
profile is guided by two locating pins.
Now carefully lower the slide onto the
platform.
