890557_d•en•01.07.2014 We reserve the right to carry out improvements
49
7.2.3 Temperature control
The automatic temperature mode of the Wisotronic permits, in conjunction
with temperature sensors (in the control unit, weather station), enables the
temperature-dependent control of your sun shading product. A sensor for the
room temperature is already integrated in the device itself (internal device
sensor). In addition, the Wisotronic can measure the "Outside temperature"
value via a weather station.
NOTE The temperature control can assess either the internal device sensor OR an
external sensor (weather station) but not several at the same time.
Example Sample application:
Weather station
In the Wisotronic:
temperature
measuring value
Channel 1:
external
venetian
blind
Fig. 14 Temperature control application example
The Wisotronic is installed in the living room.
Channel 1 controls the external venetian blind in the conservatory depending
on the temperature in the conservatory, measured internally in the Wisotronic
(the value "Temperature inside" from channel 1).
The outside temperature is measured with a weather station. The external
venetian blind is subject to ice monitoring and is raised in time before freez-
ing.
Temperature control
