80
P07-11
Parameter name
Setting
method
Effective
time
Default
Range
Category
Unit
Acceleration and
deceleration time of the
1st segment displacement
Operation
setting
Effective
immediately
100
1 to 65535
-
ms
Used to set the time when the motor in the multi-segment position is uniformly accelerated from 0rpm to the
P07-10 (maximum speed of the 1st segment displacement) in the multi-segment position.
P07-12
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Waiting time after
completion of the 1st
segment displacement
Operation
setting
Effective
immediately
100
1 to
65535
-
Set by
P07-06
Used to set the waiting time before running the next segment displacement after the multi-segment position of
the 1st displacement is completed
P07-13
Parameter name
Setting
method
Effective
time
Default
Range
Category
Unit
The 2nd segment
displacement
Operation
setting
Effective
immediately
10000
-2147483647 to
2147483646
-
-
P07-14
Parameter name
Setting
method
Effective
time
Default
Range
Category
Unit
Maximum speed of the
2nd segment displacement
Operation
setting
Effective
immediately
100
1 to 5000
-
rpm
P07-15
Parameter name
Setting
method
Effective
time
Default
Range
Category
Unit
Acceleration and
deceleration time of the
2nd segment displacement
Operation
setting
Effective
immediately
100
1 to 65535
-
ms
P07-16
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Waiting time after
completion of the 2nd
segment displacement
Operation
setting
Effective
immediately
100
1 to
65535
-
Set by
P07-06
P07-17
Parameter name
Setting
method
Effective
time
Default
Range
Category
Unit
The 3rd segment
displacement
Operation
setting
Effective
immediately
10000
-2147483647 to
2147483646
-
-
P07-18
Parameter name
Setting
method
Effective
time
Default
Range
Category
Unit
Maximum speed of the 3rd
segment displacement
Operation
setting
Effective
immediately
100
1 to 5000
-
rpm
P07-19
Parameter name
Setting
method
Effective
time
Default
Range
Category
Unit
Acceleration and
deceleration time of the
3rd segment displacement
Operation
setting
Effective
immediately
100
1 to 65535
-
ms
P07-20
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Waiting time after
completion of the 3rd
segment displacement
Operation
setting
Effective
immediately
100
1 to
65535
-
Set by
P07-06
