WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
Specialized, Concentrated, Focused - 149 -
Name
Setting Range
Default
Value
When
Enabled
Refer-
ence
MM as revolving axis unit
Yes: mm
No: degree
No
After restart
-
Pulse Equivalent of Y
revolving axis
0.0001~1 (deg/p)
0.006
After restart
-
Revolving Workpiece
radius
0~100000 (mm)
10
After restart
-
Startup speed of revolving
axis
0~100000(rad/s)
0.2909
Immediately
-
Acceleration speed of
revolving axis
0 ~100000 (mm/ s
2
)
6.9813
Immediately
-
MAX speed of revolving
axis
0.06~250 (Related to pulse
equivalent setting) (n/min)
30
Immediately
-
A axis program unit
0:degree
1:mm
0
Restart
-
Startup speed of A axis
0~100000
0.3
Immediately
-
Acceleration speed of A
axis
0.001~100000
6.9813
Immediately
-
Max speed of A axis
0.06~41.66667
30
Immediately
-
Control radius of A axis
0~100000
10
Immediately
-
Screw Error Comp
0: No compensation
1: Unilateral
2: Bilateral
0
After restart
3.11.1
Backlash Compensation
Valid
Yes: Valid
No: Invalid
No
After restart
3.11.1
Enable AQE
Compensation
Yes: Valid
No: Invalid
No
After restart
3.11.3
AQE Compensation Time
0~0.3015 (sec)
0
After restart
3.11.3
AQE Compensation
Length
0~10 (mm)
0
After restart
3.11.3
Delay of AQE
Compensation
0~10 (sec)
0
After restart
3.11.3
Intensity of AQE
Compensation
0~1
0.75
After restart
3.11.3
Lift Height for DXF
0~99999 (mm)
1
Immediately
3.13.3
Cutting Depth for DXF
-99999~0 (mm)
-1
Immediately
3.13.3
Enable First Point as
WCS Zero
Yes: Valid
No: Invalid
Yes
Immediately
3.13.3
Enable Single Shape
Cutting
Yes: Valid
No: Invalid
No
Immediately
3.13.3
Enable Flat Bottom
Cutting
Yes: Valid
No: Invalid
No
Immediately
3.13.3
Force Metric Unit in DXF
Yes: Metric
No: Inch
No
Immediately
3.13.3
Enable ENG Tool
Selection
Yes: Valid
No: Invalid
Yes
Immediately
3.13.3
Enable ENG Tool No.
Change
Yes: Valid
No: Invalid
Yes
Immediately
3.13.3
Tool Change Notification
Yes: Valid
No: Invalid
Yes
Immediately
3.13.3
Lift Height for ENG
0~100000 (mm)
1
Immediately
3.13.3
Retract Distance
0~100000 (mm)
1
Immediately
3.13.3
Cycle Times for ENG
-
1
Immediately
3.13.3
Deep hole machining
0: Reciprocating chips removal
0
Immediately
3.13.3
