WEIHONG 200 Series Manufacturer's Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
- 150 - Specialized, Concentrated, Focused
Name
Setting Range
Default
Value
When
Enabled
Refer-
ence
manner
1: High speed reciprocating
chips removal
Lift Height for PLT
0~100000 (mm)
5
Immediately
3.13.3
Plt Unit
0~100000 (mm)
40
Immediately
3.13.3
Tool step
0~100000 (mm)
0.025
Immediately
3.13.3
Machining depth
-
-1
Immediately
3.13.3
Turn on radius
compensation
Yes: Valid
No: Invalid
No
Immediately
3.11.2
Specify Type of Tool
Compensation
1: Normal type
2: Intersect type
3: Insert type
1
Immediately
3.11.2
Tool Mag. Capacity
1~20
10
After restart
3.18.3
Current Tool No.
1~ Tool Mag. Capacity
1
Immediately
3.18.3
Currently Tool Mag. No.
1~ Tool Mag. Capacity
1
Immediately
3.18.3
Tool Change Notification
Yes: Prompt
No: Not prompt
No
Immediately
3.18.3
Automatic Tool Meas.
after Tool Change
Yes: Measure
No: Not Measure
No
Immediately
3.18.3
T0 Handle Mode
0: Disable T0; 1: Discharge
Loaded tool to magazine and
keep empty; 2: Set initial tool
No. from 0
0
After restart
3.18.3
Tool change upper
position
- (mm)
-1
Immediately
3.18.3
Tool change lower
position
- (mm)
0
Immediately
3.18.3
X change tool position
- (mm)
0
Immediately
3.18.3
Y change tool position
- (mm)
0
Immediately
3.18.3
X coordinate of tool
change
- (mm)
0
Immediately
3.18.3
Y coordinate of tool
change
- (mm)
0
Immediately
3.18.3
Z coordinate of tool
change
- (mm)
0
Immediately
3.18.3
Tool change speed
0.001~MAX Axial Velocity
(mm/min)
3000
Immediately
3.18.3
Z axis CTup and CTdown
speed
0.001~ Rapid Traverse Speed in
Tool Change (mm/min)
60
Immediately
3.18.3
Traversing speed in/out
tool magazine
0.001~ Rapid Traverse Speed in
Tool Change (mm/min)
60
Immediately
3.18.3
Tool change delay
0~600000 (ms)
500
Immediately
3.18.3
Return Prior Position after
tool change
Yes: Valid
No: Invalid
No
Immediately
3.18.3
T1 Position (X) in MCS
- (mm)
0
Immediately
3.18.3
T1 Position (Y) in MCS
- (mm)
0
Immediately
3.18.3
T1 Position (Z) in MCS
- (mm)
0
Immediately
3.18.3
