DISASSEMBLY
I
ASSEMBLY
Alternator Drive Pulley
1.
Lock
the
flywheel
in place.
2.
Remove
the
crankshaft
screw.
3.
Draw
out
the
drive
pulley.
(When reassembling)
255.0
to
274.6
N·m
Tightening
torque
Crankshaft
screw
26.0
to
28.0 kgf·m
188.1
to
202.5 ft·lbs
Alternator Drive Fan Pulley
RADIATOR
MODELS
1.
Lock
the flywheel
in
place.
2. Remove the crankshaft
screw.
3. Draw out the drive
fan
pulley.
Water
Pump and Oil Cooler
Water Pump
1. Remove the pipe band and the water
pipe_
2.
Remove the water pump
..
(When reassembling)
• When mounting the water pump, take
care
not to forget
mounting the
O-ring and not to let it out of position.
Oil Cooler
1. Remove the water pipe.
2.
Remove the oil filter cartridge (2) and the oil cooler joint screw.
3.
Remove the oil
cooler.
39.2
to
44.1
N·m
Tightening
torque
Oil
cooler
joint
screw
4.0
to
4.5 kgf·m
28.9
to
32.5 ft·lbs
COOLER
OIL
FILTER
(2)
Englne~
& Generators
26
WATER
PIPE
ORIVE
PULLEY
CRANKSHAFT
SCREW
/,0'//-<1>.
-WATER
PUMP
To Next Page
