4.14.3.3 Control box E71
The control box E71 is installed on the engine or in the engine room and has switches below the
LDU-20.
Fig 4-19 Control box E71 with option SPC
Legend
001 LDU-20 003 SCR bypass switch
002 SPC bypass switch
X92DF
AA00-9270-00AAA-043B-A
