Table 5-2 - iELBA - error indication shows the possible iELBA error indications related to the
number of flashes of the indicator light.
NOTE: The error indications are active in automatic mode and in manual mode.
Tab 5-2 iELBA - error indication
Number of
flashes
Status iELBA state
1 Start OK, “Boost to Control Speed Threshold” not OK OFF
2 Start OK, “Setpoint Speed” not OK in 60 s OFF
3 Start OK, speed OK, “Phase Synchronisation” not OK in 60 s OFF
4 Overspeed error OFF
5 Electric motor error OFF
6 The lubricating oil pressure is too low OFF
7 iELBA pickup sensor error OFF
8 TDC pickup sensor error Usual operation
9 BDC pickup sensor error Usual operation
X92DF
AA00-7752-00AAA-043A-A
Operation Manual Integrated electrical balancer (iELBA)
Winterthur Gas & Diesel Ltd.
- 241 - Issue 002 2020-08
