Fig 4-25 LDU-20 page - LP SCR PAGE INDEX
Tab 4-5 LP SCR PAGE INDEX
Item Function Effect
001 INDEX button Opens the index page
002 SCREENSHOT button Makes a screenshot of the current screen
003 RCS CTRL ON button Gets control from the remote control system (if button is ac-
tive)
004 Page button Opens the selected page
X92DF
AA00-9270-00AAA-043B-A
Operation Manual LP Selective catalytic reduction system
Winterthur Gas & Diesel Ltd.
- 119 - Issue 002 2020-08
