WinGD X92DF - System Oil System (Generic and Simplified)

Fig 4-4 System oil system (generic and simplified)
001
001
003004005006
008
007
012
010
009
27
23 22
22
23
25
30
011
37
002
002
26
ENGINEPLANT
ENGINE PLANT
Legend
001 Turbocharger 007 Crosshead
002 iELBA (optional) 008 Thrust bearing
003 Torsional vibration damper (optional) 009 Oil sample valve
004 Axial vibration damper 010 Lever
005 Main bearing 011 Supply pipe to servo oil system
006 Crank bearing 012 Piston
X92DF
AA00-0000-00AAA-043B-A
Operation Manual System oil system
Winterthur Gas & Diesel Ltd.
- 85 - Issue 002 2020-08
