WinGD X92DF User Manual

NOTE: For a description of the exhaust ventilation refer to section 2.7 Prevention of
explosions in the exhaust gas system (gas mode).
Tab 6-10 EXHAUST VENTILATION
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 PRINT button Makes a screenshot of the current screen, refer to section
6.8.31 LDU-20 page - SCREENSHOT
006 INDEX button Opens the INDEX page
007 Manual Ventilation Request button Sends a signal for ventilation request (Ventilation Request
“Manual”)
008 Aux. Elect. SO Pump start button Starts and stops the auxiliary electrical servo oil pump
NOTE: The green indicator light shows that you should start
the auxiliary electrical servo oil pump for sufficient
servo oil pressure.
NOTE: You only can start the auxiliary electrical servo oil
pump, if the conditions that follow are OK:
•
Green indicator light is on
009 Start Aux. Blowers button Starts and stops the auxiliary blowers
NOTE: The green indicator light shows that you should start
the auxiliary blowers for ventilation.
NOTE: You only can start the auxiliary blowers, if the condi-
tions that follow are OK:
•
Green indicator light is on
•
Shutdown signal is reset
010 Cancel Exhaust Ventilation button
WARNING
Explosion hazard. Cancel the exhaust ventilation only in
an urgent situation. Gas could stay on the engine side, if
the exhaust ventilation is not sufficient.
Stops the exhaust ventilation
NOTE: The control system stops the auxiliary blowers and
auxiliary electrical servo oil pump.
X92DF
AA00-9606-11AAA-043B-A
Operation Manual LDU-20 page - EXHAUST VENTILATION
Winterthur Gas & Diesel Ltd.
- 321 - Issue 002 2020-08
