Tab 6-12 FAILURE LIST
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 LOG MSG button Opens the LOG MESSAGE page
006 INDEX button Opens the INDEX page
007 Filter button Manually select the applicable type filter for the related failure
008 Filter button Manually select the applicable category filter for the related
failure
009 Scroll bar Manually scroll through the failure list
X92DF
AA00-9606-13AAA-043B-A
Operation Manual LDU-20 page - FAILURE LIST
Winterthur Gas & Diesel Ltd.
- 325 - Issue 002 2020-08
