Tab 6-17 GAS ADMISSION VALVES
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 PRINT button Makes a screenshot of the current screen, refer to 6.8.31
LDU-20 page - SCREENSHOT
006 INDEX button Opens the INDEX page
007 GAV Feedback status Shows the status of the stroke sensor of the gas admission
valve (GAV)
008 GAV Actuator status Shows the status of the actuator of the gas admission valve
(GAV)
X92DF
AA00-9606-18AAA-043B-A
Operation Manual LDU-20 page - GAS ADMISSION VALVES
Winterthur Gas & Diesel Ltd.
- 335 - Issue 002 2020-08
