Tab 6-21 LOG MESSAGES
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 PRINT button Makes a screenshot of the current screen, refer to 6.8.31
LDU-20 page - SCREENSHOT
006 INDEX button Opens the INDEX page
007 Selected log message Shows the selected log message with a blue background
008 List of log messages Shows the messages with the latest message at the bottom
009 Filter button Manually select the applicable filter for the log messages
010 Scroll bar Manually scroll through the log messages
X92DF
AA00-9606-22AAA-043B-A
Operation Manual LDU-20 page - LOG MESSAGES
Winterthur Gas & Diesel Ltd.
- 343 - Issue 002 2020-08
