NOTE: Some data on this screen are only applicable to WinGD SW developers, eg the ID and
status flag numbers.
Tab 6-37 LOG ENTRY DATA
Item Function Effect
001 START AST button Starts the engine in astern direction (for reversible engine)
002 STOP button Stops the engine
003 START AHD button Starts the engine in ahead direction
004 CTRL. TR. button Sends a signal for a control transfer to this LDU-20
005 INDEX button Opens the INDEX page
006 Acknowledge button Has no function
007 Module identifier Shows the source module that sent this log entry
008 Message type Shows the message type. Shows Info, Error, Event, Safety
009 Description Shows general data about the log entry
010 Recommended action Shows recommended action that the operator can do to solve
the problem
X92DF
AA00-9606-39AAA-043B-A
Operation Manual LDU-20 page - LOG ENTRY DATA
Winterthur Gas & Diesel Ltd.
- 377 - Issue 002 2020-08
