Tab 6-45 MAIN
Item Function Effect
001 Indication field Shows data for start interlocks and for limiters
Start interlock Info: Turning Gear Engaged, Main Start Air
Valve Closed, Exhaust Venting Request, Shaft Locking Device
Engaged
Limiter Info: Torque Limiter Active, Scavenge Air Limiter Ac-
tive, Torque + Scavenge Air Limiter Active
002
Fuel mode
Shows the fuel mode
Shows: Diesel, Transfer, Gas, Gas - DCC Active, Fuel Shar-
ing, Diesel - Manual
003 Gas System Shows data for the gas system
Shows: Available, Int. Gas Trip, Ext. Gas Trip, Transfer Prep.,
Operational
004 Control Shows the control mode
Shows: Brigde, ECR Remote, ECR Manual, Local
005 Engine Shows the engine status
Shows: Air Run, Slowturning, Start Interlock, Stopped, Shut-
down, Running, Starting, Heavy Start, Angle Determining,
Slowdown
X92DF
AA00-4618-01AAA-043B-A
Operation Manual MCP page - MAIN
Winterthur Gas & Diesel Ltd.
- 397 - Issue 002 2020-08
