WARNING
Injury Hazard: Make sure that no personnel are near the flywheel or the engine, before
you operate the turning gear.
6 Operate the turning gear until the cam (006, Figure 10-9) is at the highest position.
7 Remove the claw (004) and the screw (003).
8 Turn the roller lifting tool (002) 180° until the mark (001) points down.
9 Remove the roller lifting tool (002).
10 Install the plug (004, Figure 10-8) to the supply unit (003).
11 Install the cover to the supply unit (003).
12 Make sure that the fuel pump (002) operates correctly.
13 Make sure that the HP fuel pipe (001) has no leaks.
CLOSE UP
• None
X92DF
AA00-5556-00AAA-730B-A
Operation Manual Connect the fuel pump
Winterthur Gas & Diesel Ltd.
- 560 - Issue 002 2020-08
