WinGD X92DF User Manual

Tab 11-13 Exhaust gas system (XX37NN)
Description Usual op-
eration
(value or
range)
Safeguard setting
Medium / physical value / location Signal number Func-
tion
Le-
vel
Trigger
value
De-
lay
Exhaust pipe / manifold
Exhaust gas / temperature [°C] / outlet each
cylinder
- TE3701-nnA ALM H ≥ 515 0
ALM D ≥ 50 0
SLD H ≥ 530 60
SLD D ≥ 70 60
Exhaust gas / temperature [°C] / inlet each
turbocharger
- TE3721-nnA ALM H ≥ 515 0
SLD H ≥ 530 60
Exhaust gas / temperature [°C] / outlet each
turbocharger
- TE3731-nnA ALM H ≥ 340 0
SLD H ≥ 380 60
X92DF
AA00-0000-00AAA-033B-A
Operation Manual List of usual values and safeguard settings
Winterthur Gas & Diesel Ltd.
- 588 - Issue 002 2020-08
