Fig 13-3 Signal codes
PT 1012 C
001 002 003 004
00207
Legend
001 Function code 003 Running number
002 Function group 004 Applied system
Tab 13-1 Function code
Code First position Second position
A Analysis n/a
C Control Control
E n/a Element
F Flow n/a
G Gauge n/a
H Hand n/a
I n/a Indication
J Power n/a
L Level n/a
P Pressure n/a
S Speed Switch
T Temperature Transmitter
V n/a Valve
X Unclassified Unclassified
Y Vibration Relay
Z Position (binary) n/a
X92DF
AA00-0000-00AAA-043I-A
Operation Manual Schematic diagrams - general
Winterthur Gas & Diesel Ltd.
- 606 - Issue 002 2020-08
