Fig 4-8 Scavenge air system
00148
001
002
003
004
005
006
007
008
009
015
014
013
012
011
010
Legend
001 Exhaust gas manifold 009 Drains
002 Exhaust gas outlet 010 Auxiliary blower
003 Scavenge air inlet 011 Piston underside
004 Turbine 012 Piston
005 Compressor 013 Scavenge air receiver
006 Scavenge air cooler 014 Cylinder liner
007 Water separator 015 Exhaust valve
008 Charging unit
X92DF
AA00-0000-00AAA-043S-A
Operation Manual Scavenge air system
Winterthur Gas & Diesel Ltd.
- 93 - Issue 002 2020-08
