Wolf COB-2 - TS Stratification Cylinder Components

Description
3066501_201910 WOLF GmbH | 11
3.3 TSstraticationcylindercomponents














Fig. 3.3 TSstraticationcylindercomponents
q Heating return 1“
w DHW connection ¾“
e Regulated TS stratication pump
r Immersion pipe cylinder sensor
t Plate heat exchanger
y Stratication sensor
u Cylinder primary pump (PP)
i Heating ow 1"
o Cold water connection ¾" (optional accessory)
a Expansion vessel, 8 l (accessory)
s Air vent valve
d Circulation pump (accessory)
f Protective anode (under cover)
g Drain
