Planning
3066501_201910 WOLF GmbH | 25
>20 >30
Fig. 4.6 Minimum shaft size [mm]
4.6.6 Notes on connection
i
Original WOLF components have been optimised over many years and are designed for use with
WOLF heat generators.
Connection type Maximum length
horizontalair/ue
gas routing
Please note the following:
Type B23
Moisture-resistant ue
systems (open ue)
3 m – Flue gas chimney must have CE approval.
Type B33
Moisture-resistant ue
systems (open ue)
3 m (when installed
in a ue gas
chimney)
– Flue gas chimney must have CE approval.
– Obtain the connection piece from the chimney
manufacturer.
– The air apertures to the boiler room must be
completely free from obstruction.
Type C43x
Moisture-resistant balanced
ue chimney (room sealed)
3 m (when installed
in a balanced ue
chimney)
– Flue gas chimney must have CE approval.
Type C53, C83x
Moisture-resistant ue (room
sealed)
3 m – Recommended: maximum length of horizontal
supply air pipe 3 m
– Special requirements for ues that are not
surrounded by combustion air in accordance
with locally applicable combustion regulations
Type C63x
Combustion air supply and
ue gas systems (room
sealed and open ue) which
have not been tested with
the oil ring site
3 m – If using third party equipment that is only
CE/DIBT approved, the contractor will be
responsible for the correct sizing and perfect
function of the system.
– No liability for faults, material losses and injuries
resulting from incorrect pipe lengths, excessive
pressure drop, premature wear with escaping
ue gas and condensate or incorrect functions,
e.g. through components working loose.
– Recommended: maximum length of horizontal
supply air pipe 3 m
– If the combustion air is drawn from the shaft,
the shaft must be free from contamination.
Moisture-resistant ue with
two- or multiple-draught
chimneys
- – Requirements of DIN 18160-1 Supplement 3
– Inform the local ue gas inspector prior to
installation.
