Wolf COB-2 - HG14: Function Output A1

Parameter settings
60 | WOLF GmbH 3066501_201910
Ex f msg
w/o sh
External fault (e.g. fault contact of condensate removal pump)
When contact E1 is open, fault message 116 is generated.
Heating and DHW heating will remain active.
The fault message is cancelled by closing contact E1.
Table 7.2 Function input E1
7.2.7 HG14: Function output A1
Read and congure parameter HG14 using the BM-2 programming unit or the AM display module directly
at the heat generator.
Display Description
None None (factory setting)
Output A1 is ignored by the control unit.
DHWcirc
100
DHW circulation pump 100%
Output A1 is switched by the time program in the control accessory if DHW circulation has
been enabled.
Output A1 is constantly switched if no accessory controller is installed.
DHWcirc
50
DHW circulation pump 50%
Output A1 is switched cyclically by the time program in the control accessory if DHW
circulation has been enabled.
5 minutes ON, 5 minutes OFF. Output A1 is switched cyclically if no accessory controller is
installed.
DHWcirc
20
DHW circulation pump 20%
Output A1 is switched cyclically by the time program in the control accessory if DHW
circulation has been enabled.
2 minutes ON, 8 minutes OFF. Output A1 is switched cyclically if no accessory controller is
installed.
Flame Flame detector
Output A1 is switched after a ame has been recognised.
Flue gas
damper
Flue gas/ventilation air damper
Output A1 is switched rst before each burner start. The burner will only be enabled after
input E1 has been closed. Closed contact E1 is a prerequisite for enabling the burner in
heating, DHW and emissions test mode.
A fault is generated (FC8) if output A1 is switched and input E1 does not close or open within
1 minute.
If output A1 is congured as a ue gas damper, input E1 is automatically programmed as a
ue gas damper and disabled for other settings.
Zirkomat Zirkomat (DHW circulation remote control)
Output A1 is activated for 5 minutes when input E1 closes.
After input E1 has been switched off and 30 minutes have elapsed, the Zirkomat function is
re-enabled for the next operation.
Alarm Alarm output
If a fault has occurred and 4 minutes have passed, the alarm output is activated. There is no
notication of warnings.
Ext vent. External ventilation
Output A1 is switched inversely to the ame signal.
Switching off external ventilation (e.g. extractor fan) during burner operation is required only
if the heat generator is operated in open ue mode.
Fuel valve External fuel valve
Activates an additional fuel valve during burner operation.
Output 1 is activated from the pre-purging of the heat generator until burner shutdown.
HCP Heating circuit pump
For HG40 system conguration 1, output A1 is switched parallel to the feed/heating circuit
pump.
If HG40 system conguration is set to 12, output A1 is automatically enabled as the output
for a heating circuit pump (direct heating circuit).
Table 7.3 Function output A1
