Installation
3066501_201910 WOLF GmbH | 45
Terminal Explanation
LP (PP) Cylinder primary pump
Maximum of 1.5 A per output, no more than 600 VA in total
A1 Programmable output (HG14) 230 VAC, e.g. DHW circulation pump
Maximum of 1.5 A per output, no more than 600 VA in total
E1 Programmable input (HG13), e.g. ue gas damper or room thermostat
E2 5kNTC common sensor = header
Alternative 0-10 V control, e.g. 8V = 80% heating output
The maximum external voltage at input E2 is 10 V. Anything higher will destroy the control
PCB 1(a) = 10 V, 2(b) = GND.
AF 5 k NTC outside sensor
SF 5kNTC cylinder sensor
eBus (WOLF control accessories e.g. BM-2, MM-2, KM-2, SM1-2, SM2-2)
NOTE
Increased electromagnetic interference at the installation site!
Possible control faults.
► Fit screened sensor leads and eBus cables.
► One end of the cable shield must be connected to the PE potential in the control unit.
5.10.6 Connecttheuegasdampertothepowersupply(cascadeoperationonly).
► Open the lower casing cover of the HCM-2.
► Strip insulation from the power cable of the damper motor and signal contact.
► Pull the Rast5 plug from output A1.
► Push the power cable of the ue gas damper motor through the strain relief (insert) and secure.
► Terminate the cores at the Rast5 plug A1 and insert the plug.
► Pull the Rast5 plug from input E1.
► Push the limit switch cable of the ue gas damper motor through the strain relief (insert) and secure.
► Terminate the cores at the Rast5 plug E1 and insert the plug.
► Close casing cover.
5.11 Connectingthestraticationcylinder
► Set the ON/OFF switch of the cylinder primary pump to constant pressure (Fig. 6.3 Cylinder primary
pump).
CirculationinconjunctionwithTSstraticationcylinder
The circulation control system of the heat generator prevents the stratied water from mixing during draw-
off and charging.
► Connect the circulation to the programmable output of the heat generator.
