Planning
22 | WOLF GmbH 3066501_201910
4.6.3 Permitted connection types
Type COB-2-15/20/29/40
Appliance type
1, 2, 3
B23, B33, C33x, C43x, C53, C53x, C63x, C83x, C93x
Operating mode
Open ue Yes
Room sealed Yes
Can be connected to
Moisture-resistant chimney B23, B33, C83x
Balanced ue chimney C43x
Air/ue gas routing C33x, C53x, C93x
Certied air/ue gas routing C63x
Moisture-resistant ue B23, C53x, B33
1
An x indicates that all components of the ue are surrounded by combustion air and meet higher requirements for gas tightness.
2
For types B23 and B33, the combustion air is drawn from the installation room (open ue combustion equipment).
3
For type C, the combustion air is drawn through a sealed system from the outside (room sealed combustion equipment).
Table 4.8 Permitted connection types
The following balanced ues or standard ues with CE-0036-CPD-9169003 certication may be used
(Table 4.9 Permissible air/ue gas routing lengths [m]):
Flue DN60 Flexible ue DN83
Concentric balanced ue DN60/100 Flue DN110
Flexible ue DN60 Flexible ue DN 110
Flue DN80 Concentric balanced ue DN110/160
Concentric balanced ue DN80/125 Flue DN 160 (for cascade operation)
Concentric balanced ue (on an external wall)
DN80/125
The necessary type plates and certicates are included with the relevant WOLF accessories.
4.6.4 Air/uegasroutinglengths
The calculation was made taking the pressure conditions into account (geodetic height: 325 m). The
specied lengths refer to concentric balanced ues and standard ues and apply to original WOLF
components only.
Maximum length
Type Design variants
Maximum length [m]
1
COB-2 15 20 29 40
B23
Flue in a shaft and combustion air directly via heat
generator (open ue)
DN 60 20 - - -
DN 80 30 30 30 -
DN 110 - - - 30
B33
Flue in a shaft with horizontal, concentric connecting
pipe (open ue)
DN 60 18 - - -
DN 80 30 30 30 -
DN 110 - - 30
B33
Connection to a moisture-resistant ue gas chimney
with a horizontal concentric connection pipe (open
ue)
Calculation according to DIN
EN 13384 (balanced ue
chimney manufacturer)
C33x
Vertical concentric roof outlet through pitched or at
roof, vertical concentric balanced ue system for
installation in a shaft (room sealed)
DN 60/110 9 - - -
DN 80/125 24 22 18 -
DN 110/160 - - - 14
C43x
Connection to a moisture-resistant balanced ue
chimney, maximum pipe length from centre of bend
on heat generator to connection 3 m (room sealed)
Calculation according to DIN
EN 13384 (balanced ue
chimney manufacturer)
C53
Connection to the ue in a shaft and supply air pipe
through an external wall (room sealed, supply air
pipe 4 m, 1x bend 87°)
DN 80/125 30 30 30 -
DN 110/160 - - - 30
C53x
Connection to a ue on an external wall (room
sealed)
DN 80/125 30 30 30 -
DN 110/160 - - - 30
