Wolf COB-2 - Removing; Fitting the Casing; Position the Heat Generator and Cylinder

Installation
3066501_201910 WOLF GmbH | 31
5.3 Removing/ttingthecasing
Removing the casing






Fig. 5.2 Removing the casing
► Undo the screws (1).
► Tilt the panel forwards (2).
► Remove the casing cover upwards (3).
Attaching the casing
1.
1.






Fig. 5.3 Attaching the casing
► Insert the casing cover (1).
► Put the panel in place (2).
► Tighten the screws (3).
5.4 Position the heat generator and cylinder
i
Maintain minimum wall clearances! This will simplify installation, maintenance and servicing (4.2.1
Minimum wall clearances to the front and side).
► Remove the casing (Fig. 5.2 Removing the casing).
► Use the adjustable feet to level the heat generator and cylinder
