Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
Page 112/174 © Woodward
Starting Without Closing GCB
Parameter 240
Start withno GCB
cool down ON
Only if terminal 6 has been con-
figured to "start without CB".
Perform engine cool down if starting without CB has been selected ON/OFF
ON ................ After removing the start request, an engine cool down is performed
for the time configured in Parameter 306.
OFF
.............. After removing the start request, the engine is stopped immediately
without an engine cool down.
Sprinkler Alarm Classes During Sprinkler Coasting
Parameter 241
Sprinkler shutd.
F1 active ON
Only if terminal 6 has been
configured to
"Sprinkler operation".
Sprinkler alarm classes only active if terminal 6 is active ON/OFF
ON ................ If terminal 6 is configured as "Sprinkler operation", the primary
alarm classes will be enabled again after the sprinkler coasting has
expired (energizing terminal 6 and sprinkler coasting 10 minutes).
OFF .............. If terminal 6 has been configured to "Sprinkler operation", the prima-
ry alarm classes will be enabled again after the sprinkler demand has
concluded (energizing terminal 6).
Sprinkler (Critical) Operation (onlyB + X Packages)
NOTE
The function "Sprinkler operation" must be assigned to terminal 6.
ATTENTION
Please note that terminal 6 must be energized (apply a HIGH signal) so that a Sprinkler (critical) opera-
tion is not performed. De-energizing terminal 6 (a LOW signal) initiates a Sprinkler (critical) operation 
negative logic function.
Sprinkler "ON": If the signal at terminal 6 drops to a Low signal (de-energizes), the Sprinkler (critical) opera-
tion ON command is initiated. The message "Sprinkler operation" is shown on the display. Up to 6 attempts are
made to start the engine if it is not in operation. All fault conditions, which result in a shutdown, become mes-
sages with the exceptions of terminals 34 or 61 and overspeed. The alarm input for terminal 34 retains its set
alarm class. Terminal 61 is used for this if terminal 34 is not present on the control. It is recommended that
EMERGENCY STOP be assigned to one of these terminals.
