Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
© Woodward Page 53/174
Automatic
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
Parameter 107
Configure
automatic YES
Configuration of automatic YES/NO
Parameters are grouped together in blocks to permit quicker navigation through the
large number of configuration screens. Selecting "YES" or "NO" has no effect if
controlling or monitoring is performed. This parameter has the following effects:
YES .............. The configuration screens in the next block are displayed and can ei-
ther be viewed ("Select" push-button) or modified ("Cursor→", "Di-
git↑" or "Select" push-buttons).
NO ................ The parameters in the next block are not displayed, cannot be mod-
ified and are therefore skipped.
Load Management
NOTE
To enable the automatic start/stop function, Parameter 103 “Active power load-share” must be confi-
gured to “ON”, regardless if additional generators are available for load sharing.
NOTE
To carry out an automatic start/stop of the engine, all participating controls must be configured with
the identical rated power (Parameter 32).
Load-dependent start/stop in mains parallel operation
Parameter 108
Loadd.start/stop
at ter.3 ON
Load dependent start/stop: enable via terminal 3 ON/OFF
ON ................ If the control input "Automatic 1" (terminal 3) is enabled, an auto-
matic start/stop is performed on the basis of the generator set point
real power 1 (Parameter 46). If terminal 5 is enabled simultaneously,
t
erminal 3 has priority. The subsequent screens of this function are
displayed.
OFF .............. No automatic start/stop is performed. The adjustment of the pre-
specified set point value is always carried out. The subsequent
screens of this function are not displayed.
Parameter 109
Loadd.start/stop
at ter.5 ON
Load dependent start/stop: enable via terminal 5 ON/OFF
ON ................ If the control input "Automatic 2" (terminal 5) is enabled, an auto-
matic start/stop is performed on the basis of the generator set point
real power 2 (Parameter 47). If terminal 3 is enabled simultaneously,
t
erminal 3 has priority. The subsequent screens of this function are
displayed.
OFF .............. No automatic start/stop is performed. The adjustment of the pre-
specified set point value is always carried out. The subsequent
screens of this function are not displayed.
