Manual 37278B GCP-30 Series - Genset Control

Chapter 4.

Commissioning

DANGER - HIGH VOLTAGE

When commissioning the control, please observe all safety rules that apply to the handling of live

equipment. Ensure that you know how to provide first aid in the event of an uncontrolled release of

energy and that you know where the first aid kit and the nearest telephone are. Never touch any live

components of the system or on the back of the system:

L I F E T H R E A T E N I N G

CAUTION

Only a qualified technician may commission unit. The "EMERGENCY-STOP" function must be opera-

tional prior to commissioning of the system, and must not depend on the unit for its operation.

CAUTION

Prior to commissioning ensure that all measuring devices are connected in correct phase sequence.

The connect command for the unit circuit breaker must be disconnected at the unit circuit breaker. The

field rotation must be monitored for proper rotation. Any absence of or incorrect connection of voltage

measuring devices or other signals may lead to malfunctions and damage the unit, the engine, and/or

components connected to the unit!

Commissioning Procedure:

1. After wiring the unit and ensuring all voltage-measuring devices are phased correctly, apply the control

system voltage (i.e. 12/24 Vdc). The "Operation" LED will illuminate.

2. By simultaneously pressing the two push-buttons "Digit↑" and "Cursor→", the configuration mode is ac-

cessed. After entering the access code number, the unit may be configured according to the application

requirements (see the chapter regarding the parameters).

3. After applying the measuring variables, the unit will display the measured values. These values should be

confirmed with a calibrated measuring instrument.

4. The initial start of the engine should be performed in the MANUAL operation mode (press the "MA-

NUAL" push-button). Start the engine ("START" push-button) and then stop it ("STOP" push-button).

All generator measured values must be checked. Any alarm messages should be investigated as well.

5. Check the automatic start sequence by means of the TEST operation mode (press the "TEST" push-

button). Test the protections that result in alarms with shutdowns.
