Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
Page 62/174 © Woodward
Parameter 124
Interchange Mode
in Manual ON
only RPQ Package
Interchange mode in manual ON/OFF
OFF .............. Interchange mode (enabled by the DI at terminal 126) may also be
performed in AUTOMATIC operating mode.
ON ................ Interchange mode (enabled by the DI at terminal 126) may only be
performed in AUTOMATIC operating mode.
Breaker
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
Parameter 125
Configure
breaker YES
Configuration of the breakers YES/NO
Parameters are grouped together in blocks to permit quicker navigation through the
large number of configuration screens. Selecting "YES" or "NO" has no effect if
controlling or monitoring is performed. This parameter has the following effects:
YES .............. The configuration screens in the next block are displayed and can ei-
ther be viewed ("Select" push-button) or modified ("Cursor→", "Di-
git↑" or "Select" push-buttons).
NO ................ The parameters in the next block are not displayed, cannot be mod-
ified and are therefore skipped.
Functional Description
Permissible Limits
If the generator or mains monitoring for over-/undervoltage (Parameter 201) or over-/underfrequency (Para-
m
eter 195) is disabled, the CB logic (Parameter 126) and the control system are controlled by internally defined
lim
it values.
For the busbar, always the internally defined limit values are used.
Voltage Frequency
Generator V
Gen
: 75 to 115 % V
RatedS
y
ste
m
f
Gen
: 80 to 110 % f
RatedS
y
ste
m
Busbar V
Busba
r
: 85 to 112.5 % V
RatedS
y
ste
m
f
Busba
r
: 90 to 110 % f
RatedS
y
ste
m
Mains V
Mains
: 85 to 112,5 % U
RatedS
y
ste
m
f
Mains
: 90 to 110 % f
RatedS
y
ste
m
Table 3-4: Limit values, permissible limits
The permissible limits refer to the respective rated values in the system, i.e. the rated system voltage, configured
in Parameter 23, and the rated system frequency, configured in Parameter 11.
