External expansions
Discrete input [D1.01] of IKD1.1 Option SC06 + IKD1
frei parametrierbar freely configurable
Discrete input [D1.02] of IKD1.1 Option SC06 + IKD1
Discrete input [D1.03] of IKD1.1 Option SC06 + IKD1
Discrete input [D1.04] of IKD1.1 Option SC06 + IKD1
Discrete input [D1.05] of IKD1.1 Option SC06 + IKD1
Discrete input [D1.06] of IKD1.1 Option SC06 + IKD1
Discrete input [D1.07] of IKD1.1 Option SC06 + IKD1
Discrete input [D1.08] of IKD1.1 Option SC06 + IKD1
Discrete input [D2.01] of IKD1.2 Option SC06 + IKD1
Discrete input [D2.02] of IKD1.2 Option SC06 + IKD1
Discrete input [D2.03] of IKD1.2 Option SC06 + IKD1
Discrete input [D2.04] of IKD1.2 Option SC06 + IKD1
Discrete input [D2.05] of IKD1.2 Option SC06 + IKD1
Discrete input [D2.06] of IKD1.2 Option SC06 + IKD1
Discrete input [D2.07] of IKD1.2 Option SC06 + IKD1
Discrete input [D2.08] of IKD1.2 Option SC06 + IKD1
Air-fuel-ratio sender alarm from ST 3 Option SC06 + ST3
Lambdasonde
Lambda probe
Other Events
Switched into operation mode MANUAL
BAW Hand
Manual mode
Switched into operation mode AUTOMATIC
BAW Automatik
Automatic mode
Switched into operation mode STOP
BAW Stop
Stop mode
Switched into operation mode TEST
BAW Probe
Test mode
Switched into operation mode Load TEST
BAW Lastprobe
Loadtest mode
"MCB OFF" push-button pressed (in MANUAL MODE)
Taste NLS AUS
Button MCB OFF
"GCB OFF" push-button pressed (in MANUAL MODE)
Taste GLS AUS
Button GCB OFF
"GCB ON" push-button pressed (in MANUAL MODE)
Taste GLS EIN
Button GCB ON
"MCB ON" push-button pressed (in MANUAL MODE)
Taste NLS EIN
Button MCB ON
"START" push-button pressed (in MANUAL MODE)
Taste Hand START
Button START
"STOP" push-button pressed (in MANUAL MODE)
Taste Hand STOP
Button STOP
Remote start
Fernstart
Remote start
Remote stop
Fernstop
Remote stop
Remote acknowledgment via interface
Fernquittierung
Remote acknowl.
Remote acknowledgment via terminal 6
Quittierung Kl.6
Acknowledg-ter 6
Acknowledgment via "RESET" button
Quittierg. Taste
Ackn.button QUIT
Mains failure (AMF)
Netzausfall
Mains failure
Return of the mains (this entry occurs once the mains settling time expired)
Netzwiederkehr
Mains o.k.
Emergency power (AMF) started
Notstrom Anfang
Emerg. run start
Emergency power (AMF) ended
Notstrom Ende
Emerg. run stop
Engine successfully started (engine enabled, firing speed exceeded)
Aggr. gestartet
Start of engine
Engine stopped (engine not enabled, firing speed was undershot)
Aggregatestop
Stop of engine
Table 3-2: Event recorder – Messages, part 2
Analog Inputs
The control unit is not able to display the entire text for the analog alarms. The 6 digits on the left side of the
screen are reserved for the analog values to be monitored. If the text for these alarms is expanded, the monitored
values will be overwritten and not displayed. The text below is the message that is displayed for each of the fault
conditions.
WIRE__ ........Wire break
ALARM_ ........Limit value 1
STOP__ ........Limit value 2
Parameter 8
YY-MM-DD ss:mm
STOP Analog inpu
Example
Limit value 2 (STOP) of the analog input 1 was exceeded. The text of the analog
alarm input will be moved 6 letters to the right. In this case the measured value dis-
appears. Please note this text displacing already during the configuration of the
analog input!
