Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
Page 144/174 © Woodward
Appendix B.
Relay Manager
No. Output Explanation
1 Alarm class 1
2 Alarm class 2
3 Alarm class 3
4 Firing speed reached (engine runs)
5 Mains failure; undelayed The function reacts according to the
status of the breakers. The condi-
tions described in chapter "Emer-
gency power" apply.
6 Battery undervoltage
7 AUTOMATIC operation mode
8 MANUAL operation mode
9 TEST operation mode
10 STOP operation mode
11 Generator undervoltage
12 Generator overvoltage
13 Generator underfrequency
14 Generator overfrequency
15 Generator overcurrent level 1
16 "Synchronization GCB" or "Connect GCB" time monitoring alarm
17 Engine start failure
18 Generator unbalanced load
19 Generator overload
20 Generator reverse/reduced power
21 Readiness for operation Output via relay manager
22
#1
Analog input [T1], level 1
23
#1
Analog input [T1], level 2
24
#1
Analog input [T2], level 1
25
#1
Analog input [T2], level 2
26
#1
Analog input [T3], level 1
27
#1
Analog input [T3], level 2
28
#1
Analog input [T4], level 1
29
#1
Analog input [T4], level 2
30
#1
Analog input [T5], level 1
33
#1
Analog input [T5], level 2
32
#1
Analog input [T6], level 1
33
#1
Analog input [T6], level 2
34
#1
Analog input [T7], level 1
35
#1
Analog input [T7], level 2
36 Discrete input [D01]
37 Discrete input [D02]
38 Discrete input [D03]
39 Discrete input [D04]
40 Discrete input [D05]
41 Discrete input [D06]
42 Discrete input [D07]
43 Discrete input [D08]
44 Discrete input [D09]
45 Discrete input [D10]
46 Discrete input [D11]
47 Discrete input [D12]
48 Discrete input [D13]
49 Discrete input [D14]
50 Discrete input [D15]
#1
(Package XP, Option T701)
