Parameter 14
Rated Frequency2
System 2 00.0Hz
only RPQ Package
Rated system frequency 2 50.0 to 60.0 Hz
The rated frequency of system 2 is configured here. The parameter becomes active
if the discrete input at terminal 71 is energized (refer to Discrete Input section in
Installation Manual 37320).
Parameter 15
Setpoint Frequ.
System 2 00.0Hz
only RPQ Package
Generator set point frequency 2 40.0 to 700 Hz
The generator set point frequency in system 2 is configured here. The parameter
becomes active if the discrete input at terminal 71 is energized (refer to Discrete
Input section in Installation Manual 37320).
PTs (Voltage Transformers, only B + X Packages)
WARNING
If the value of the following parameter is changed, the values of the following parameters have to be
checked:
• Generator rated voltage (Parameter 22)
• Volta
ge controller dead band (Parameter 71)
• Sy
nchronizing dVmax (Parameter 133)
• Dead
bus start GCB dVmax (Parameter 147)
• Thre
shold generator overvoltage (Parameter 202)
• Thre
shold generator undervoltage (Parameter 204)
Parameter 16
Gen.volt.transf.
secondary 000V
only B + X Packages
Secondary gen. voltage transformer [1] 50 to 125 V; [4] 50 to 480 V
L This value corresponds to the secondary voltages of the PTs, which are di-
rectly connected to the control.
The secondary voltage is set here in V. This parameter is used to display the sec-
ondary voltages on the control unit screen.
Parameter 17
Gen.volt.transf.
primary 00.000kV
only B + X Packages
Primary gen. voltage transformer 0.050 to 65.000 kV
L This value corresponds to the primary voltages of the PTs.
The primary voltage is set her in kV. This parameter is used to display the primary
voltages on the control unit screen. In the case of measured voltages of 100 V
without a measurement transducer, 00.100 kV must be set here; for 400 V =
00.400 kV.
Parameter 18
Bus.volt.transf.
secondary 000V
only B + X Packages
Secondary busbar voltage transformer [1] 50 to 125 V; [4] 50 to 480 V
L This value corresponds to the secondary voltages of the PTs, which are di-
rectly connected to the control.
The secondary voltage is set here in V. This parameter is used to display the sec-
ondary voltages on the control unit screen.
Parameter 19
Bus.volt.transf.
primary 00.000kV
only B + X Packages
Primary busbar voltage transformer 0.050 to 65.000 kV
L This value corresponds to the primary voltages of the PTs.
The primary voltage is set here in kV. This parameter is used to display the primary
voltages on the control unit screen. In the case of measured voltages of 100 V
without a measurement transducer, 00.100 kV must be set here; for 400 V =
00.400 kV.
