Chapter 1.
General Information
Type English German
GCP-31/32 series
GCP-31/32 - Installation 37239 GR37239
GCP-31/32 - Configuration this manual 37278 GR37278
GCP-31/32 - Function/Operation 37238 GR37238
GCP-31/32 - Application 37240 GR37240
Option SB - Caterpillar CCM coupling 37200 GR37200
Option SC06/07/08 - CAN bus coupling 37182 GR37182
Option SC04 - IKD1 and ST3 coupling 37236 GR37236
Option SC02 - IKD1 coupling 37302 GR37302
Option D08- Preglow control 37286 GR37286
Option T7 - 7 analog inputs 37261 GR37261
Option TZ - Temperature-dependent start/stop 37241 GR37241
more options upon request
Additional manuals
IKD 1 - Manual 37135 GR37135
Discrete expansion board with 8 discrete inputs and 8 relay outputs that can be coupled via the CAN bus to the control unit. Evalua-
tion of the discrete inputs as well as control of the relay outputs is done via the control unit.
IKN 1 - Manual 37136 GR37136
20channel NiCrNi temperature scanner that monitors the temperature values for exceeding or falling below a threshold value, meas-
ured through senders on the IKN 1. A configured relay on the board of the IKN 1 will trip. The IKN 1 can be coupled with the con-
trol unit using the CAN bus to display measuring values as well as alarms.
LeoPC1 - Manual 37146 GR37146
PC program for visualization, for configuration, for remote control, for data logging, for language upload, for alarm and user man-
agement and for management of the event recorder. This manual describes the use of the program.
LeoPC1 - Manual 37164 GR37164
PC program for visualization, for configuration, for remote control, for data logging, for language upload, for alarm and user man-
agement and for management of the event recorder. This manual describes the programming of the program.
GW 4 - Manual 37133 GR37133
Gateway for transferring the CAN bus to any other interface or bus.
ST 3 - Manual 37112 GR37112
Control to govern the air fuel ratio of a gas engine. The ratio will be directly measured though a Lambda probe and controlled to a
configured value.
Table 1-1: Manual - Overview
