Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
© Woodward Page 21/174
Measuring
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
WARNING
The following values must be entered correctly for the generator to be monitored. Failure to do so may
lead to incorrect measuring resulting in damage to or destruction of the generator and/or personal in-
jury or death.
Parameter 9
Configure
measuring YES
Configuration of the measuring YES/NO
Various parameters are grouped together in blocks to allow navigation through the
large number of configuration screens more rapidly. Selecting "YES" or "NO" has
no effect on whether or not control or monitoring is carried out. The input merely
has the following effect:
YES .............. The configuration screens in the next block are displayed and can ei-
ther be viewed ("Select" push-button) or modifications can be made
to the parameters ("Cursor→", "Digit↑" or "Select" push-buttons).
NO ................ The parameters in the next block are not displayed, cannot be mod-
ified and are therefore skipped.
Rated Values Of The Frequency
Parameter 10
Generator freq.
f set 00.0Hz
only B + X Packages
Generator set point frequency 40.0 to 70.0 Hz
The generator set point frequency is configured here. This is required for the fre-
quency controller in isolated and no-load operation. In most cases, the values en-
tered into this screen will be 50 Hz or 60 Hz. It is possible to configure other values
into this parameter.
Parameter 11
Rated system
frequency 00.0Hz
only B + X Packages
Rated system frequency 50/60 Hz
The rated system frequency is the value that the generator is going to connect to.
This parameter is dependent on the individual country or individual system.
Parameter 12
Rated Frequency1
System 1 00.0Hz
only RPQ Package
Rated system frequency 1 50.0 to 60.0 Hz
The rated frequency of system 1 is configured here. The parameter becomes active
if the discrete input at terminal 71 is not energized (refer to Discrete Input section
in Installation Manual 37320).
Parameter 13
Setpoint Frequ.
System 1 00.0Hz
only RPQ Package
Generator set point frequency 1 45.0 to 65.0 Hz
The generator set point frequency in system 1 is configured here. This is required
for the frequency controller in isolated and no-load operation. In most cases, the
values entered into this screen will be 50 Hz or 60 Hz. It is possible to configure
other values into this parameter. It is possible to configure other values into this pa-
rameter. The parameter becomes active if the discrete input at terminal 71 is not
energized (refer to Discrete Input section in Installation Manual 37320).
