Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
Page 82/174 © Woodward
Connect Time Monitoring (With Induction/Asynchronous Generators Only)
If Parameter 154 is configured to "ON", closing time monitoring is performed: A timer is started when the clos-
ing of the GCB is initiated following the termination of the delayed engine monitoring. If the breaker has not
closed following the expiration of the configured time, an F1 alarm message is issued.
Parameter 155
Switch.time cntr
ON
Breaker close time monitoring ON/OFF
ON ................ Connect time monitoring is carried out. The subsequent screen of this
function is displayed.
OFF .............. Unsuccessful connection is not monitored. The subsequent screen of
this function is not displayed.
Parameter 156
Switch.time cntr
delay 000s
Delay of breaker close time monitoring 2 to 999 s
When the closing of the GCB is initiated, a timer is started. If the GCB has not
closed before the expiration of the timer, a warning message "Connect time GCB"
is issued. A further attempt is made to connect the power circuit breaker. The relay
assigned relay manager function 16 (GCB) and/or 70 (MCB) is energized.
Issuing of class F1 alarm
