Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
Page 150/174 © Woodward
MUX
No.
Contents (words)
Unit Note
6/2 20
Configuration [T1]-[T4] Display in ...
#1#
°C °F bar/10 psi/10 % no unit
#1#: The analog input is not available or he
has been configured either as real power
set point value or as mains (import/export)
real power value.
Note – On double /fourfold bits the follow-
ing is valid: If the indicated bit combination
is fulfilled (
high byte and low byte) ,the
message is active (otherwise inactive).
Analog input [T4]
Bit 15 = 0 0 0 1 1 1 0
Bit 14 = 0 1 1 0 0 1 0
Bit 13 = 0 0 1 0 1 0 1
Bit 12 = 0 1 0 1 0 0 1
Analog input [T3]
Bit 11 = 0 0 0 1 1 1 0
Bit 10 = 0 1 1 0 0 1 0
Bit 9 = 0 0 1 0 1 0 1
Bit 8 = 0 1 0 1 0 0 1
Analog input [T2]
Bit 7 = 0 0 0 1 1 1 0
Bit 6 = 0 1 1 0 0 1 0
Bit 5 = 0 0 1 0 1 0 1
Bit 4 = 0 1 0 1 0 0 1
Analog input [T1]
Bit 3 = 0 0 0 1 1 1 0
Bit 2 = 0 1 1 0 0 1 0
Bit 1 = 0 0 1 0 1 0 1
Bit 0 = 0 1 0 1 0 0 1
6/3 21
Engine speed measured via the Pickup min
-1
7/1 22
Generator current in L1 A × 10
IGNEXPO
7/2 23
Generator current in L2 A × 10
IGNEXPO
7/3 24
Generator current in L3 A × 10
IGNEXPO
8/1 25
Actual generator reactive power var × 10
PGNEXPO
positive = inductive
8/2 26
Generator cos ϕ Example: FF9EH cos ϕ = c 0,98 (capacitive)
FF9DH cos ϕ = c 0,99 (capacitive)
0064H cos ϕ = 1,00
0063H cos ϕ = i 0,99 (inductive)
0062H cos ϕ = i 0,98 (inductive)
8/3 27
Current reserve power in the system kW
9/1 28
Current actual real power in the system kW
9/2 29
Number of participants on the CAN bus
9/3 30
H.B. Mains status
L.B. Generator status
FFH Voltage and frequency available
00H Voltage and frequency not available
10/1 31
Exponents High Byte: IGNEXPO Generator current
Low Byte: --- free
10/2 32
Busbar frequency Hz × 100
